| Model | CM106 |
|---|---|
| Related old webpage model | M106 / CM-106 |
| Product type | Tri-Mode Lightweight Gaming Mouse |
| Connectivity | 2.4GHz wireless / Bluetooth / Wired USB |
| Main sensor configuration | PixArt 3311 |
| Main solution | BK3633 |
| Optional high configuration | PixArt 3395 with DPI up to 26000 |
| Button configuration | 6D |
| Lighting | No lighting in the main promoted configuration |
| DPI levels | 800 / 1600 / 2400 / 4800 / 7200 / 12000 DPI |
| Optional high-configuration DPI | Up to 26000 DPI |
| Left and right switch lifetime | Huanyu switches, up to 50 million clicks |
| Encoder | TTC encoder, approximately 300,000 cycles |
| Battery capacity | 500mAh rechargeable battery |
| Charging interface | Type-C |
| Cable specification | OD3.0 braided cable, approximately 1.5 m |
| Mouse dimensions | 123 × 66 × 43 mm |
| Net weight | Approximately 50–55 g |
| Design | Ergonomic right-handed design |
| Suitable hand size | Medium to large hands |
| Recommended grip styles | Palm grip / Claw grip / Other grip styles |
| Material | ABS plastic |
What connection modes does the ANEEX CM106 support?
The ANEEX CM106 supports Tri-Mode connectivity, including 2.4GHz wireless, Bluetooth and wired USB connections.
What is the main configuration of the CM106?
The main promoted configuration uses a PixArt 3311 sensor, BK3633 solution, 6D button configuration, adjustable DPI up to 12000 and a 500mAh rechargeable battery.
What DPI levels does the CM106 support?
The CM106 supports multiple adjustable DPI levels: 800, 1600, 2400, 4800, 7200 and 12000 DPI.
Is a higher-performance configuration available?
Yes. A higher configuration using a PixArt 3395 sensor and DPI up to 26000 is listed for project discussion. The final configuration should be confirmed according to the order requirements.
How many buttons does the CM106 have?
The CM106 features a 6D button configuration designed for practical gaming and everyday control functions.
What is the switch lifetime of the CM106?
The CM106 uses Huanyu left and right switches rated for up to 50 million clicks.
What encoder does the CM106 use?
The CM106 uses a TTC encoder rated for approximately 300,000 cycles.
What is the battery capacity of the CM106?
The CM106 is equipped with a built-in 500mAh rechargeable battery for wireless operation.
How is the CM106 charged?
The CM106 uses a Type-C charging interface and includes an approximately 1.5m braided data cable for charging and wired use.
What are the dimensions and weight of the CM106?
The CM106 measures approximately 123 × 66 × 43 mm and weighs approximately 50–55 g.
What type of grip is suitable for the CM106?
The CM106 uses an ergonomic right-handed design suitable for medium to large hands and different grip styles, including palm and claw grips.
Are charging dock or display options available?
Optional charging dock, HUB and RGB lighting configurations can be discussed for project requirements. A color screen option is also listed as an optional configuration in the quotation.
Can the CM106 be customized for OEM and ODM projects?
Yes. The CM106 can be discussed for OEM and ODM projects, including colors, sensor configuration, lighting options, charging dock, branding, packaging and other project-specific requirements.
